　　FUNKTION ONE----MST10

　　Features:

　　1. Large composite waveguide, the first diffusion and focus control

　　2.Funktio n - One design, broadband segment, 1 0 "driver

　　3. Unique load, providing very high language intelligibility in many environments with poor acoustic conditions

　　4. Lightness

　　5. Optional coaxial high frequency horn

　　6. Different diffusion angles are optional

　　7. Direct hanging point

　　8. Waterproof structure

　　9.40° and 60° versions have the same size flare

　　① Driver 10"

　　Frequency band 150HZ-6K5Hz

　　MST1040 sensitivity (1w@1m) 113dB

　　MST1060 sensitivity (1w@1m) 111dB recommended amplifier power (rms) 250W nominal impedance 16Ω

　　②Driver 1.4"

　　Frequency band 4.5K HZ-18K Hz

　　MST1040 sensitivity (1w@1m) 109dB

　　MST1060 sensitivity (1w@1m) 108dB recommended amplifier power (rms) 75W nominal impedance 16Ω

　　Weight: MST1040 65KG MST1060 60KG

　　Nominal diffusion angle: MST1040 40°horizontal×20°vertical

　　MST1060 60°horizontal×20°vertical

　　Material: extra light composite material

　　Interface: Industrial grade spring terminal block

　　Funktion-One made a major breakthrough in the search and development of horns with composite structures when providing the sound system for the London Millennium Egg. M ST horn combines new design structure and material integration, strength, lightness, waterproof and excellent acoustic performance. This composite structure technology enables large-scale waveguide to be manufactured to make it practical. Coupled with Funktion-One's unique paper drive loading technology, the weight of the entire MST horn is only 65 kg. The nearly 2-meter waveguide, combined with the special disk driver, provides non-collocated sound quality, sensitivity, high sound pressure, and directivity control. When the waveguides are combined into a vertical link, the pointing control can be adjusted from 10 to 22.5° to get the desired sound pressure and sound coverage.

　　The MST horn has been installed in the ice hockey venues and bobsled venues of the 2014 Sochi Winter Olympics in Russia.

　　In terms of professional audio, while providing its own services, Shenzhen Mateng Audio Technology Co., Ltd. is a professional audio company integrating R&D, design and sales. With professional technology, perfect management and forward-looking positioning on the market, it has won the favor of users and channel network partners all over the country.

　　Shenzhen Mateng Audio Technology Co., Ltd. mainly undertakes the design, installation and commissioning of various types of audio system projects. In line with the principle of "doing the right thing for customers and helping customers gain more benefits", after years of concerted efforts of all employees, many large, medium and small projects have been completed all over the country, such as bars, mass-market KTVs, nightclubs, etc. Design, construction and installation of sound system engineering.
