F88 uses two 8" drivers designed by Funktion-One, and a slot-shaped tweeter, with a crossover frequency higher than 6kHz , especially focusing on the optimal connection of the drive unit.
F88 uses two 8" drivers designed by Funktion-One, and a slot-shaped tweeter. The crossover point is higher than 6kHz, especially the optimal connection of the driver unit. The diffusion angle of F88 is 110°, 99dB sensitivity, And the frequency response is from 70Hz to 18kHz, it is suitable for many occasions, such as KTV booths, bars, banquet halls, auditorium supplementary sound boxes and home AV sound systems on the lower floor of the theater that are blocked by the boxes. F88 can support full-range sound And you can use Funktion One's bass series speakers to make it more perfect, such as MB212 or F118.
characteristic:
•Wide diffusion angle
•Wide response frequency band
• Funktion-One design 8" drive
• Optional face mesh form
driver | Sensitivity (1 w@1 m) | Recommended power amplifier (rms)* | Nominal impedance |
2×8" Trough high frequency | 99dB | 400W | 6Ω |
AES standard
Frequency response ± 3 dB: | 70Hz - 1BkHz |
weight: | 13kg (28.5lbs) |
Nominal diffusion angle: | 110° horizontal × 40° vertical |
interface: | 2 × Speakon NL4 |
