Bass Reflex Range Bar hall sound Vendor

Funktion-One's brand new Bass Reflex low-frequency reflection series speakers, are designed to be used in indoor entertainment venues such as nightclubs, bars, etc. that require low and powerful, or used as high-quality, high-performance return low-frequency parts.

Project Details

Funktion-One's brand new Bass Reflex, low-frequency reflection series speakers are designed to be used in indoor entertainment venues such as nightclubs, bars, etc. that require low and strong power, or used as high-quality, high-performance return low-frequency parts. The unique design and adjustment make the speaker relatively smaller and more analytical than other similar products. The high degree of analysis means that the speaker can be used for higher crossover points, that is to say, it is more versatile, and it provides frequency adjustability to be used in the low frequency extension of Funktion-One's many different full-range speakers.



BR121/BR22: It can provide deep ultra-low frequency, which is very suitable for F215MK2 , R2, R3 and other speakers.

BR218: Multi-purpose subwoofer, in addition to being used as a subwoofer, it can also be used as a high-end low frequency speaker.

BR118: A near-field low-frequency loudspeaker with a compact and relatively small cabinet, which is very suitable for F88 , F1201, R1 and other loudspeakers.

BR115: A low-frequency speaker with high performance in a compact and relatively small cabinet . It is very suitable for F81, F101, R1 and other speakers. It is ideal for smaller applications such as recording and transmission.





characteristic:

•Extremely strengthened and sturdy cabinet, providing clear low frequency

• Wear-resistant powder-coated steel surface

•Integrated handle

•Optional M20 threaded pole mount

• Pulley options (only available in BR221 and BR218)

• Relatively small size, easy to manage (BR118 and BR115)

• All are made of 18mm Baltic multi-layer compression board

• 2×Speakon NL4 sockets, (BR221 and BR218 sockets, 1+/1- and 2+/2- each connected to a driver)



model

driver

Frequency band

Sensitivity

(1w@1m)

Recommended power amplifier

(Rms)*

Nominal impedance

weight

BR221

2×21"

30-270Hz

104dB

1300W

2×8Ω

Total 4Ω

120Kg (265lbs)

BR121

1×21"

32-270Hz

103dB

650W

66Kg (146lbs)

BR218

2×18"

35-300Hz

104dB

1100W

2×8Ω

Total 4Ω

70Kg (152lbs)

BR118

1×18"

37-300Hz

103dB

550W

38Kg (84lbs)

BR115

1×15"

45-320Hz

103dB

500W

33Kg (73lbs)


Bass Reflex Range(图1)
