Resolution 5S is a 3-way, as long-distance, 100Hz or more speakers, has a unique patented ax waveguide, in addition to increasing the capacity and efficiency of the projection angle of the speaker, but also increased the 8 "RF output drive cone, this means that you can be a high -frequency compression driver crossover point up to 6kHz , compared to other intermediate frequency compression driver is the speaker, significantly reducing distortion
Resolution 5S is a 3-way, long-distance, 100Hz or more speaker, with a unique patented axe-shaped waveguide. In addition to increasing the efficiency and projection angle of the speaker, it also increases the high-frequency output of the 8" cone driver. This means that the crossover point of the high-frequency compression driver can be increased to 6kHz, which significantly reduces distortion compared to other speakers with a compression driver at the mid-frequency. Resolution 5S provides high density, controlled diffusion angle and the same as the full cabinet version Sound quality. It is suitable for use in bars, nightclubs, opera houses, etc. All performance venues, Resolution 5S can play unimaginable high-quality, high-efficiency, high-resolution and high-definition beautiful music and singing. For some weight restrictions For the venue, the choice of Resolution 5S with neodymium magnet drive version complements each other even more.
characteristic:
• Greatly reduce weight
• Greatly reduce sound processing and no need for equalizer to adjust the tone
• The same sound quality as the full cabinet version
•Controlled diffusion angle
• FunktionOne design driver
• Optional lightweight neodymium magnet drive
• Equipped with installation lifting points
driver | Frequency band | Sensitivity (1w@1m) | Recommended power amplifier (Rms)* | Nominal impedance |
12" | 114-445Hz | 105dB | 300W | 8Ω |
8" | 445-7k55Hz | 111dB | 200W | 16Ω |
1" | 5k77Hz-above | 113dB | 50W | 16Ω |
*AES standard
Frequency response ±3dB: | 114Hz-18kHz |
weight: | 50kg |
Nominal diffusion angle: | 25°horizontal×20°vertical |
interface: | Industry standard spring terminal |
